Expandable 10-Channel Data Logger
The DL10 Data Logger is our base model that offers 12 channels in a compact aluminum package. Easily upgradeable to 20 or 28 channels, it's the perfect starting point for the racer that wants a basic data logging system to build on. Its small size allows mounting in many locations.
3 RPM Channels (Engine, Clutch, Driveline, Wheel Speed, GPS)
1 ACCELEROMETER Channel (Forward G-force Meter)
4 ANALOG Channels (0-5v Pressure, Temp, Shock Travel, etc.)
3 DIGITAL Channels (WOT Switch, N2O Stages, etc.)
1 BATTERY VOLTAGE Channel (Via Expansion Module)
Includes RPM Pro Software
This unit REQUIRES an expansion to 20 or 28 Channels via our Expansion Modules. Battery voltage will not be recorded without connected Expansion Module. If you do not require an expansion module, please see our Basic Data Logger.
Dimensions: 5” x 4” x 1”
Requires: Power Cable, Remote Start Cable, USB to Serial Converter, and DB9 Serial Cable
